Power: 40w
Solar panel:18V 60W
Lithium battery:12.8V 24AH
Install height: 6m-7m
Material: Aluminum Alloy
Size: 1180*330*145MM
integrated solar street light | Item NO.:JKC-KM-40W-motion sensor | ||
Solar panel | Max power | 18V 60W(Imported High Efficiency Monocrystalline Silicon) | |
size | 1070*272*4.5MM | ||
Life time | 25years | ||
Battery | Type | LifePO4 Battery 12.8V 307.2WH/ 24AH | |
size | 142*290*36MM | ||
Life time | 5-8years | ||
LED Lamp | Max power | 40W | |
led chip brand | Bridgelux 3030 / lumileds3030 | ||
LED Efficacy | 171LM/W | ||
System Efficacy | 95LM/W | ||
lumen (LM) | 3800LM | ||
Life time | 100000hours | ||
Viewing Angle | TYPE 2 | ||
LED Lamp | 144 PCS | ||
Charge time | by sun | 6hours | |
Discharge time | 3 Cloudy/Rainy days | ||
working Temperature | range( ℃ ) | -25℃—+65℃ | |
colour temperature | range(k) | 2700K-6500K(customized) | |
mounting height | range (m) | 6-7M | |
space between light | range (m) | 20-25M | |
Lamps material of main | aluminium alloy | ||
with remote control or not | yes / Night Sensor+Microwave Motion Sensor | ||
Certificate | CE / ROHS / IP65 / ISO | ||
warranty period | 5years | ||
Packing & Weight | Product size | 1180*330*145MM | |
Net weight | 19KG | ||
Gross weight | 21KG | ||
Packing size | 1200*400*200MM | ||
Qty/ctn | 1set/ctn | ||
Packing | neutral | ||
Packs Containers | 20GP | 280sets | |
40GP | 570sets | ||
40HC | 680sets |
